HUNT ENDURO WIDE MTB WHEELSET - 27.5" Boost / 29" Boost & Super Boost / 6 Bolt Only

LAB DEVELOPED, RACE PROVEN. THE ENDURO WIDE IS OUR ALL-OUT, HARDEST-HITTING WHEELSET FOR YOUR ENDURO RIG.

27.5" / 29" / MULLET | 33F/31R WIDE INT. | 2,105G

"Hunt bike에서는 이 휠이 헌트 라인업중 가장 강한 휠이라고 주장해서 휠슬러의 바위와 숲길에서 그에 준하는 테스트를 하였다. 세계 최정상의 높이의 지역에서 큰 바위와 바위사이를 라이딩하면서 이 휠은 전혀 틀어짐없이 정렬을 유지했다." ENDURO WIDE 27.5" REVIEW

THE PURPOSE

헌트 디자인팀은 약 3년간의 지역 트레일 코스와 EWS 코스에서 휠 서비스를 제공하면서 많은 수상과 표창을 받았지만 최근의 라이더들의 필요의 진화에 대응할 수 있도록 헌트의 Enduro Wide wheelset을 업그레이드할 필요성을 느꼈다. EWS 코스의 선수들의 의견을 경청하면서 머뭇거림없이 험한 트레일 코스를 과감하게 공략할 수 있는 휠셋을 만들기 위해 포로토타입을 개발하였고 충격 테스트 리그를 개발하여 FEA (Finite Element Analysis)를 사용하여 무게제한의 문제점이 없으면서 가장 강한 림을 개발하기 위해 소재배분을 최적화하였다. 앞뒤 휠의 필요를 더욱 충족시키기위해서 전륜은 33mm 내부폭으로 후륜은 31mm 내부폭을 적용하였고 전륜은 핸들링과 그립을 강화하고 후륜은 높은 충격을 다룰 수 있도록 하였다.

CHARACTERISTICS

RIMS I 완전히 새롭게 다시 디자인되어 전륜은 33mm 내부폭을 후륜은 31mm 내부폭을 적용하여 각 휠의 역할을 재대로 수행하도록 하였다. 2.35"-2.6" 튜브리스 타이어에 최적화된 Enduro Wide rim은 과격한 코너링이나 내리막에서 타이어를 확실하게 지지해준다.

RIM PROFILE I 다른 헌트휠셋과 같이 헌트 MTB line-up 또한 모두 튜브리스 레디가 적용되며 림 베드의 어깨부분에 'up-kicks'를 가진 H-Lock rim bead를 채용하여 타이어를 보다 확실하게 채결되게 해준다. 또한 이로 인하여 타이어가 좌우로 움직이는 현상을 막아주어 타이어가 빠지는 것을 방지해준다.

FRONT HUB I 헌트 XCWide와 TrailWide wheelset보다 프론트 허브에 보다 공을 들여 증대시켜 더 크고 매우 강한 베어링과 7075-T6 알로이 액슬을 적용할 수 있는 대구경 쉘을 사용하여 강도를 대폭 증대하였다. 매우 공격적인 트레일을 효과적으로 공략할 수 있는 능력을 갖추도록 하는 것이 목적이였다.

REAR HUB I 그 어느 때보다 터프해진 엔듀로 라이딩의 필요를 감안하여 헌트 EnduroWide hub는 17mm 대구경 액슬을 적용하여 강도와 베어링 내구성을 증대하였다. 후륜의 Hunt RapidEngage MTB hub는 빠른 5도의 체결각도를 가져 코너에서 즉각적인 파워를 지면에 전달할 수 있게 되었다.

SPOKES I 스포크 헤드가 강화된 최상급의 triple butted Pillar Spokes를 적용하여 매우 가벼우면서도 스트레스가 증가되는 라이딩 상황에서도 더 높은 유연성을 가진다. Pillar Spoke Reinforcement (PSR)는 J-Bend부분이 스트레스로 문제가 생기지 않도록 헤드 부분에 소재를 추가적으로 사용한 스포크이다.

FREEHUB BODY I SRAM/Shimano 8/9/10/11sp, Shimano Microspline, SRAM XD 선택 가능

SPECS OVERVIEW

WE SEE WHEELS AS A SYSTEM, NOT A SINGLE COMPONENT

• Rims | 6069 T6 (490 MPa, + 69% Ultimate Tensile Strength over 6061-T6) 용접 구조. 33mm/31mm 내부 폭 적용, work-hardened shot-peened finish.
• Hubs | 대구경 NDRO 전륜 허브. 5 degree RapidEngage 후륜 허브. Boost (110/148 ) spacing. 대구경 이중 실드 카트리지 베어링. Rock Shox Torque Caps for Boost hubs 가능.
• Spokes | 전륜 28개 후륜 32개 Spoke 적용. Triple Butted (2.2-1.6-2.0) PSR reinforced Pillar Spokes.
• Tires | 2.35"-2.6" 튜브리스 타이어에 최적화된 휠로 2.25"-2.8" 타이어 사용도 가능하다. 일반 튜브와 타이어 장착도 가능하다.
• Axles | 강도 증대를 위해 더 두꺼운 17mm 7075-T6 액슬 적용하여 허브의 휨현상도 줄이고 베어링의 수명도 연장시켜준다.
• Weight | 2,105g (29")
• Rider Weight I 짐을 포함한 최대 허용 무게 120kg이며 라이더의 몸무게가 110Kg 을 초과할 경우 정기적으로 미케닉으로부터 휠점검을 받을 것을 권장드립니다. 최대 공기압은 40psi.

RECOMMENDED TIRES

• FRONT: Schwalbe Magic Mary 2.35" Snake Skin Super Soft
• REAR: Schwalbe Hands Dampf 2.35" Snake Skin Super Soft

IN THE BOX

• Black Shield PET high tensile strength tubeless tape fitted to wheels.
• Freehub fitted
• Tubeless Valves
• Spare of each spoke plus nipples
• Quality control card signed by your wheel builder

보증 기간: 3 YEARS

원산지: MADE IN TAIWAN

HUNT ENDURO WIDE MTB WHEELSET - 27.5" / 29" Boost & Super Boost

LAB DEVELOPED, RACE PROVEN. THE ENDURO WIDE IS OUR ALL-OUT, HARDEST-HITTING WHEELSET FOR YOUR ENDURO RIG.

27.5" / 29" / MULLET | 33F/31R WIDE INT. | 2,105G

"Hunt bike wheels claim that these are the toughest wheels in their line up, and I really did try to put that statement to the test on the rocks and wood of Whistler. All this science made sure that when I rode Top of the World and pin-balled from large rock to large rock, my wheel stayed perfectly true and there wasn’t a ding in sight." ENDURO WIDE 27.5" REVIEW

THE PURPOSE

After almost three years of valiant service on local trails and EWS stages alike, with numerous awards and accolades along the way, the restless design team here at HUNT saw an opportunity to update the Enduro Wide wheelset to meet the evolving demands of today’s riders.Listening to our athletes on the EWS circuit, we developed a testing protocol to ensure the Enduro Wide can take a beating on the most unforgiving trails without flinching. Our engineers built an impact test rig specifically for the task, then using FEA (Finite Element Analysis) they optimised the material distribution ensuring the strongest rim without incurring a weight penalty.To better suit the differing needs of each wheel, a front (33mm int.) and rear (31mm int.) specific profile is utilised; designed for compliancy and grip up front, while the back is reinforced to handle high impacts. So, whether you're riding tracks with black diamonds marked at the trail head or spend the weekends chasing your next Enduro stage, the EnduroWide has your back.

CHARACTERISTICS

RIMS I Re-designed from the ground up so your wheels are the least of your worries as you focus on the stage ahead. Offering up mixed rim widths (33/31mm internal) to handle the different tasks front and rear wheels face. Optimized for 2.35"-2.6" tyres, the EnduroWide rim provides support to the tyre during hard cornering or hucking off that step-down you've been eying off for a few months!

RIM PROFILE I Like all of our wheels, the Hunt MTB line-up is designed to be used as a tubeless system. Featuring a H-Lock rim bead with 'up-kicks' to the shoulders of the rim bed secures your tyre when seated. This prevents side-to-side movement reducing the chance of burping your tyre. It creates a great rim-well seal for first installation and easy sealing of tubeless tyres. Still haven't made the switch? All our wheels are tube compatible as well.

FRONT HUB I We have gone all out on the front hub and beefed it up over our XCWide and TrailWide wheelsets. Featuring an oversized shell to accommodate larger and extremely durable bearings and 7075-T6 series alloy axles to increase stiffness. These hubs have been selected based on their ability to perform on the most aggressive trails.

REAR HUB I The demands of modern day Enduro riding are tougher than ever before, so the EnduroWide hubs have been designed with oversized 17mm axles to increase stiffness and bearing durability. On the rear, the Hunt RapidEngage MTB hubs with a fast 5 degree engagement, means you will be able to put the power down straight out of the corners.

SPOKES I We have chosen top of the line, triple butted Pillar Spokes with increased reinforcement at the spoke head. Not only are these spokes extremely lightweight, they are also able to provide a greater degree of elasticity when put under increased stress. The Pillar Spoke Reinforcement (PSR) puts more material at the spoke head, just before the J-Bend to prevent failure in this stress area.

FREEHUB BODY I Choose between SRAM/Shimano 8/9/10/11sp, Shimano Microspline or SRAM XD to be fitted to your Enduro Wides.

SPECS OVERVIEW

WE SEE WHEELS AS A SYSTEM, NOT A SINGLE COMPONENT

• Rims | 6069 T6 (490 MPa, + 69% Ultimate Tensile Strength over 6061-T6) welded construction, 33mm/31mm wide (internal), work-hardened shot-peened finish.
• Hubs | Large body NDRO front hub and 5 degree RapidEngage rear hub, boost (110/148 ) spacing. Large double sealed cartridge bearings. Rock Shox Torque Caps for Boost hubs are available.
• Spokes | 28F/32R Spoke Count, Triple Butted (2.2-1.6-2.0) PSR reinforced Pillar Spokes.
• Tires | Optimised for 2.35"-2.6" tires set up Tubeless, but also work very well with 2.25"-2.8". Also great with standard tires and tubes
• Axles | Extra thick 17mm 7075-T6 axles for increased strength and stiffness. Reducing flex in the hub also helps to increase bearing life.
• Included | Tubeless tape, valve & spokes
• Weight | 2,105g (29")
• Rider Weight I 120kgs is the upper recommended rider weight limit for these wheels. Please include the weight of any luggage in your total rider weight when choosing the correct wheels. If a rider is over 110Kgs then an experienced bike mechanic should check the wheel regularly and it is advisable to use tires at max 40psi as this will reduce the fatigue on the wheelset.

RECOMMENDED TIRES

• FRONT: Schwalbe Magic Mary 2.35" Snake Skin Super Soft
• REAR: Schwalbe Hands Dampf 2.35" Snake Skin Super Soft

IN THE BOX

• Black Shield PET high tensile strength tubeless tape fitted to wheels.
• Freehub fitted
• Tubeless Valves
• Spare of each spoke plus nipples
• Quality control card signed by your wheel builder

WARRANTY: 3 YEARS

MADE IN TAIWAN
